Nitto 21A PVC tape 25mm x 20m

Retroceder

Cuenta
Configuración

Nitto PVC 21A is a premium grade PVC tape coated with a rubber-based pressure sensitive adhesive. PVC 21A is accepted as a top quality general use vinyl tape.

The Nitto PVC 21 is a heavy duty general purpose tape which is ideal for wire and cable harnessing, color coding, duct sealing, corrosion preventing, holding and protection.

Descargar hoja de producto
Cargando...

Nitto PVC 21A is a genuine “soft” tape. No fillers of any kind are used to guarantee excellent physical properties.

A good balance between adhesion strength, unwind force and film flexibility assures outstanding workability, high conformability and good sealing properties.

The tape has a good resistance against moisture, oils and solutions with acids and alkaline. Nitto PVC 21A is a 190 micron thick insulating tape and is suitable for a wide range of applications. The PVC tape is suited for outside use thanks to the good ageing and weatherability properties

Nitto PVC tapes distinguish itself from cheaper tapes in the following points:

  • pure plasticized PVC (no fillers)
  • non-sticky sides
  • good weatherability
  • good sealing properties
  • high conformability
  • excellent workability
  • WEEE compliant (2002/96/CE)
  • RoHS compliant (2002/95/CE)
  • good moisture and chemicalresistant

Product sheet Nitto tape 21A

Nitto tape
  1. Rubber-based pressure sensitive adhesive
  2. Primer
  3. Plasticized PVC film
Properties Value Test Method
Total thickness 0,19mm IEC 60454-2 §4
Tensile strength length direction 220N/10mm² (section)
42N/10 mm width 		 IEC 60454-2 §8
Elongation length direction 250% IEC 60454-2 §8
Adhesion to BA steel 1,92 N/10mm IEC 60454-2 §11
Adhesion to backing at 23°C 1,75 N/10mm IEC 60454-2 §11
Electrical strength at room temperature 11,0kV IEC 60454-2 §17
Volume resistance 1x1014 Ohm/25mm width IEC 60454-2 §7.6
Low temperature properties (-10°C) no degradation IEC 60454-2 §9
Flammability flammable IEC 60454-2 §19
Max. Operating Temperature +90°C IEC 60454-2 §21
Más Información
Más información

Application guidelines

  • The tape should be applied on a clean and dry surface.
  • Apply the tape with a moderate tension and with an overlap of 50%.

http://www.filoform.com/nitto-tape

Availability

If the color or size is not listed in our standard product range on our website, we can order it for you. The minimum order quantity is 10 full boxes per type / color. Below you will find an overview of the possibilities.

Colours:

  • transparent
  • black
  • blue
  • green
  • red
  • grey
  • yellow
  • white
  • brown
  • light blue
  • orange
  • yellow-green

Widths:

  • 12 mm
  • 15 mm
  • 19 mm
  • 25 mm
  • 30 mm
  • 38 mm
  • 50 mm
  • 100 mm

Lengths:

  • 10 m
  • 20 m

Core diameter: 31.5 mm
Definición Nitto 21A PVC tape 25mm x 20m
Home page product list No
Solicitar productos
Elementos de artículos agrupados
SKU Nombre del producto Dimensiones

Enter the quantities you want to order / request.


Keep the quantities equal to the Order unit

 Order unit 		Cantidad
800350.1 A Nitto tape 21A 25mmx20m black 25mm x 20m x 0,19mm Order unit 128 pcs/carton
800350.2 A Nitto tape 21, 25mm x 20m blue 25mm x 20m x 0,19mm Order unit 96 pcs/carton
800350.3 A Nitto tape 21A, 25mm x 20m green 25mm x 20m x 0,19mm Order unit 128 pcs/carton
800350.4 A Nitto tape 21A, 25mm x 20m red 25mm x 20m x 0,19mm Order unit 128 pcs/carton
800350.5 A Nitto tape 21A, 25mm x 20m transparant 25mm x 20m x 0,19mm Order unit 128 pcs/carton
800350.6 A Nitto tape 21, 25mm x 20m yellow 25mm x 20m x 0,19mm Order unit 96 pcs/carton
800350.7 A Nitto tape 21A, 25mm x 20m white 25mm x 20m x 0,19mm Order unit 128 pcs/carton
800350.9A Nitto tape 21, 25mm x 20m yellow/green 25mm x 20m x 0,19mm Order unit 96 pcs/carton
800350.x Other colours on request 25mm x 20m x 0,19mm Order unit 3072 pcs/pallet
